Advanced Power Management for Next-Generation Medical Carts Enabling 24/7 Mobile Healthcare with Dual-Voltage (12V/24V)

Enabling 24/7 Mobile Healthcare with Dual-Voltage (12V/24V) Reliable Power

1. Project Overview

In modern clinical environments, Mobile Workstations (Medical Carts) are essential for Point-of-Care (POC) nursing, bedside charting, and medication dispensing. A leading medical equipment integrator approached us to develop a robust, integrated power system capable of driving multiple peripherals with different voltage requirements while ensuring 100% uptime.

2. The Challenge

The client’s high-end nursing carts required a sophisticated power architecture to support:

• Diverse Voltage Needs: 12V DC for medical-grade monitors and thin clients, and 24V DC for motorized height-adjustment columns and specialized diagnostic tools.

• Harsh Operating Cycles: Carts are used across three shifts (24/7), requiring fast charging and long cycle life.

• Safety & Compliance: The system had to meet stringent medical safety standards (IEC 60601-1) to ensure patient and operator safety.

3. Our Solution: The Intelligent Dual-Output Power System

We engineered a custom LiFePO4 (Lithium Iron Phosphate) battery system integrated with a smart power management module.

Technical Specifications:

• Input: Universal AC 100V–240V (50/60Hz) with medical-grade isolation.

• Dual Output:

  Channel 1: 12V DC (Stable 10A) for computing and peripherals.

  Channel 2: 24V DC (Peak 8A) optimized for motorized lift actuators.




• Battery Chemistry: LiFePO4 (3000+ deep discharge cycles).

• Communication: SMBus/RS485 for real-time State-of-Charge (SoC) and Health (SoH) monitoring.

Key Features:

• Seamless UPS Functionality: The system features a "Zero-Transfer Time" switch. When the AC cord is unplugged, the cart switches to battery power instantly without rebooting the onboard computer.

• Fast Charging Technology: Achieves 90% charge in under 3 hours while simultaneously powering the cart’s equipment.

• Smart BMS Protection: Integrated protection against over-charge, over-discharge, short-circuits, and thermal runaway.

4. The Results

The implementation of our power system transformed the client’s product performance:

• 60% Weight Reduction: Improved cart maneuverability and reduced nurse fatigue.

• Extended Service Life: The battery lifespan increased from 1 year (Lead-acid) to over 5 years, significantly lowering the Total Cost of Ownership (TCO).

• Increased Efficiency: Reduced downtime for charging allowed for more "time at the bedside" for healthcare providers.

• Regulatory Success: Successfully passed all medical-grade EMC and safety certifications on the first attempt.

The battery solution for the medical cart you need
If you are looking for batteries for computer trolleys and instant care workstations, CLF's experts can help you. Our batteries can help you improve the workflow in medical institutions.
